SoleoSonoStim

Multi-frequency ultrasound and 2-channel electrotherapy combination unit

By combining versatility and ease of use, Zimmer MedizinSystems’ Soleo line meets the dynamic requirements of today’s busy physical therapy clinic.

The Soleo line is available as 3 separate modalities:
- electrotherapy
- ultrasound therapy
- combination therapy
Designed to meet all your requirements:

Speed: direct access via simple, innovative menus

Simplicity: large, professionally designed color touch screen with intuitive interface

Safety: all treatment parameters are visible at a glance

Efficiency: over 50 years of experience condensed into a detailed treatment guide

Creativity: your individualized treatments stored in memory

Preference: direct access to your preferred programs via the “FastPath” button

Features

2 channel electrotherapy unit
Multiple waveforms with complete customization
Touch screen interface
“Fast path” option allowing for ultimate customization
Pre-set programs with clinical indications for quick reference
Multi-frequency ultrasound unit with patented SonoSwing technology ranging from 0.8 – 2.4 MHz
2 sound head sizes available(1cm and 5 cm; unit comes standard with 5 cm)
Coupling light for correct contact

Specific Programs

The combination of Sono and Stim allows unparalleled flexibility and variety of treatment programs. In addition to ultrasound therapy and electrotherapy, SonoStim offers outstanding specific combined treatments. An undeniable therapeutic bonus.

Memory

The SD memory card allows programs and individualized 1 or 2 channel or combination treatments to be stored. A modern solution enabling practitioners to utilize the full capacity of the SonoStim and easily monitor patients’ treatment parameters.

Treatment Guide

Quick access to more than 300 treatment recommendations by anatomical references for treating acute and chronic pain, muscle reeducation and more.

Patented SonoSwing

“Swing” Through the Treatment Range With Our Patented SonoSwing

Ever wondered how to treat with ultrasound at the correct depth – right where the problem is? Introducing the SoleoSonoStim with patented SonoSwing.

With therapeutic ultrasound, the depth of penetration is dependent on the carrier frequency. Most ultrasounds on the market have two such frequencies – one for surface treatment, and one for depth. You can only select one or the other – with no variation in between.

The Soleo SonoStim allows you to run both frequencies through the same sound head in the same treatment, and you can select the percentage for each frequency. You can “swing” through the treatment range from surface to depth to anywhere in between! That is SonoSwing

Lower frequencies (0.8 to 1.5 MHz) are optimally effective at greater depths, while higher frequencies (2.4 to 3.0 MHz) act more on the surface.

Applicator with Coupling Light

A coupling light gives you a visual to make sure you have appropriate contact. Now all you need is a green light and you are ready to go. The Soleo SonoStim with SonoSwing – the ultimate in ultrasound therapy!

Soleo SonoStim includes a high quality, multi-frequency ergonomic ultrasound applicator. It is equipped with a coupling light and adjustable audible signal to indicate appropriate contact for optimum treatment. A green light indicates correct contact.

When coupling is not 100%, the screen will also indicate the percentage of transfer.

Channel Menu

Intuitive programming makes starting treatment quick and easy. A simple touch gives the user access to any type of stimulation:

1 or 2 Channel Synchronized Alternate Separate

Individualized Treatment

Each patient’s treatment parameters can be unique. Using active windows, it is now possible to modify or adapt the parameters in a matter of seconds and store them on the SD memory card.

Specific Programs

All current waveforms including:

Monophasic
Biphasic
TENS
Medium Frequency
Interferential
High Volt
Micro-Current
Premodulated IFC

Optional Accessory

Move Cart move_front

portable cart for Soleoline modalities
modern design
storage drawer

Technical data

Ultrasound

1 socket for one 5 cm² multi-frequency water tight head
optional 1 cm² applicator available

Frequencies

0.8 MHz: deep effect
2.4 MHz: superficial effect

Maximum power emission 3 W / cm² for the 5 cm² applicator Programs 9 programs Modes Continuous and pulsed 20 Hz, 50 Hz, 100 Hz Pulse: 1/2, 1/3, 1/5, 1/10

Electrotherapy

Synchronized, Alternate, Separate, Sequential Current Types Monophasic, Biphasic, TENS, Medium Frequency, Inferential, High Volt, Micro Current, Premodulated IFC Channels 2 independent channels (programs, intensities, parameters) Programs More than 50 specific programs Specific Modules Muscle rehabilitation / Sports rehabilitation

Hardware

SD memory card 1GB SD memory card / 120 memory entries + favorites entries Accessory Support 2 supports supplied with all versions Dimensions Width 13 in / Height 5.1 in / Depth 8.7 in / Weight 4.4 lb Optional Accessories Move Carts, designed for Soleoline with a special magnetic holder for improved cable management
